AceCrew Brass Solenoid Valve Viton 3/8 inch NPT 220VAC, 240VAC Normally Closed - flow control valve for fluid, gas, air
US$11.88
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by blizzdubiouz.ch
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
US$11.88
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by blizzdubiouz.ch
Free 30-day returns Details
Product details
| Management number | 232055916 | Release Date | 2026/06/18 | List Price | US$11.88 | Model Number | 232055916 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- AceCrew Industrial grade Electric Solenoid Valve Normally Closed with Viton FKM/FPM seal
- Size 3/8 inch NPT thread ,Voltage 220V , 240V AC
- Brass inlet & outlet NPT thread , easy to install with 2-way 2-position direct lift diaphragm
- VAC actuated valve , Normally Closed operation for gas and liquid flow control. Valve will open for flow when energized. Flow rate Cv = 0.71 ; Unidirectional (indication on brass body)
- Pipe Size : 3/8 inch NPT Female (18 TPI) . Orifice Diameter : 1/5" (5 mm)
- Seal: Viton FKM/FPM, fluorocarbon Diaphragm : Viton (fiber-reinforced) Current : 0.1 Amp . Wattage : 24 Watt. Operating Pressure Differential : 0-145 psi (0-1 MPa, gravity-feed capable)
- Solenoid actuated Valve with Viton seal is suitable for Low viscosity fluid, Water, air, natural gas, propane, butane, petroleum oil, mineral oils, diesel, gasoline
- Viton FKM seal is better resistant to heat , reducing risks of leaks during operation and ensuring a tight sealing when actuated . Operating Temperature : 15-125 °F (-10~50 °C).To avoid damaging the coil , this valve is not recommended to be in continuous use for more than 8 hours in a single cycle. Media Temperature : 15-250 °F (-10~120 °C)
- Weight of solenoid valve : 15 oz
| UPC | 610877609079 |
|---|---|
| ASIN | B0842X4JK7 |
| Size | 3/8 inch NPT |
| Brand Name | Ace Crew |
| Unit Count | 1.0 Count |
| Valve Type | Diaphragm Valve , Solenoid Normally Closed Viton 3/8 inch 220vac |
| Thread Size | 3/8 inch |
| Thread Type | NPT |
| Manufacturer | Ace Crew |
| Model Number | Normally Closed Viton 3/8 inch 220V AC |
| Material Type | Brass port, Coil : Copper wire in resin-molded casing, Diaphragm : Viton (fiber-reinforced), Seal : Viton FKM/FPM, fluorocarbon |
| Connector Type | DIN |
| Item Type Name | Viton Normally Closed Solenoid Valve 3/8 Inch volt 220VAC , 240VAC |
| Exterior Finish | Brass |
| Number of Ports | 2 |
| Maximum Pressure | 145 Pound per Square Inch |
| Specification Met | DIN, NPTS, Viton FKM seal |
| Included Components | Brass NPT thread body 3/8 Inch Normally Closed , Viton FKM/FPM seal, Electromagnetic Coil Solenoid 220V, 240V AC , Viton Diaphragm fiber reinforced |
| Inlet Connection Size | 0.38 Inches |
| Inlet Connection Type | FNPT |
| Outlet Connection Size | 0.38 Inches |
| Outlet Connection Type | FNPT |
| Manufacturer Part Number | Viton 3/8'' 220V, 230V, 240V AC |
